AZ D40 W 9/16

a high-quality Radio Tubular Motor (AZ D40 R) designed to automate blinds and shades. It's powered by a standard household voltage of 230/50 Hz and uses a reliable, mono-directional radio signal at 433.42 MHz for control via a remote.

Ø40 Mechanical wired tubular motor

Technology: Mechanical wired

Motor Head: Round

Nr of end limits: 2

Adjustment type: PA (Progressive Adjustment)

End limits setting tool: Flexible thumbscrew driver

Nominal voltage: 230V~ / 50Hz

Thermal time: 4 minutes in accordance with EN 60335-2-97

Obstacle detection: NO

Freeze detection: NO

System of protection: IP 44

Insulation class: II

Temperature working range: - 20°C to + 70°C

Activation: by button

Parallel connection: YES with QMC4

Radio compatibility: YES with radio receivers 433,42MHz

Made in: Tunisia

Certifications: CE - CMIM - NF - VDE

Type:

Motor

Reference:

9800403

Torque:

9 Nm

Nominal Speed:

16 Rpm

Noise Level:

52 dBA

Rated Power:

110 W

Length:

482 mm

Motor Weight:

1.05 Kg

Forecast Annual Volumes:

200

Thermal Protection Time:

4 Min.

Working Temperature:

- 20°C to + 70°C

Radio Frequency:

433,42MHz

Input Voltage:

230V~ / 50Hz

Roller Blinds

Blind Type:

Roller, Zebra, Roman

Wire-free

Remote Control
